一、锅炉除盐水制备系统与反渗透纯水脱盐水处理设备的概述：在电厂和水泥工厂中，为了避免锅炉结垢，提高热效率并降低燃料消耗，常采用反渗透技术。然而，如果锅炉用水含有硬度高的盐类，如钙镁离子，它们在受热过程中可能生成难以清洗的水垢，从而导致设备损坏或爆炸。因此，对于这些工业锅炉来说，进行软化或脱盐处理至关重要。在中国，这类问题导致了25%的故障率，因为传统软化设备操作复杂且可靠性差。

二、锅炉除盐水制备系统与反渗透纯水脱盐水处理设备的工艺流程：原-water tank - booster pump - quartz sand filter - activated carbon filter - anti-scaling dosing system - precision filter - reverse osmosis device - membrane chemical cleaning system- pure water tank- desalination water booster pump- ion exchange demineralization unit- desalination tank-desalination water pump

三、锅炉除盐水制备系统与反渗透纯水脱盐水处理设备的工艺说明：1. 原-water tanks store self-supplied tap water (groundwater) to avoid insufficient supply and prevent pumps from burning out due to air operation; 2. Booster pumps provide power for pre-treatment filtration, typically with a lift of 30m or less; 3. Quartz sand filters remove impurities and suspended solids in the raw water; 4. Activated carbon filters absorb chlorine ions and organic matter; 5. Anti-scaling dosing systems disperse insoluble salts, preventing them from settling on metal surfaces and protecting RO membranes; 6. Precision filters are a barrier against contamination from pre-treatment filtration equipment or residual particles; 7. Reverse osmosis devices remove metals ions and other salt impurities in the feedwater; 8.Membrane chemical cleaning systems clean polluted reverse osmosis equipment with chemicals before they can be damaged by contaminants ;9.Pure Water Tanks store RO-produced purified water ;10.Desalination Water Boosters provide power for demineralized water distribution to the boiler via demineralization units；11.Demineralized Water Tanks store desalted water；12.Demineralized Water Pumps transport desalted water to boiler feed points.
